APC

SRT6KXLI - APC SMART-UPS SRT 6000VA 230V

SRT6KXLI - APC SMART-UPS SRT 6000VA 230V

SKU:SRT6KXLI

Regular price $7,033.79 USD
Regular price Sale price $7,033.79 USD
Sale Sold out
Shipping calculated at checkout.
APC Smart-UPS On-Line,6000 Watts /6000 VA,Input 230V /Output 230V, Interface Port Contact Closure, RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB, Extended runtime model Includes: CD with software, Documentation CD, Installation guide, Removable support feet, Temperature Probe, USB cable, Warranty card



Specification:



Power
Output frequency 50/60 Hz
Output power 6000 W
Input operation voltage (min) 100 V
Input operation voltage (max) 275 V
Output operation voltage (max) 240 V
Surge energy rating 480 J
Emergency Power Off (EPO) Yes
Output voltage Total Harmonic Distortion (THD) 3%
Crest factor 3:1
Output power capacity 6 kVA
Input frequency 40/70 Hz
Performance
UPS topology Double-conversion (Online)
Waveform Sine
LED indicators Yes
Features
Output frequency 50/60 Hz
UPS topology Double-conversion (Online)
Waveform Sine
Output power 6000 W
Input operation voltage (min) 100 V
Input operation voltage (max) 275 V
Output operation voltage (max) 240 V
Surge energy rating 480 J
Emergency Power Off (EPO) Yes
Output voltage Total Harmonic Distortion (THD) 3%
Crest factor 3:1
Output power capacity 6 kVA
Input frequency 40/70 Hz
Ports & interfaces
AC outlets quantity 6 AC outlet(s)
AC outlet types NEMA L6-20R, NEMA L6-30R
USB 2.0 ports quantity 1
Serial ports quantity 1
Ethernet LAN (RJ-45) ports 1
Battery
Battery technology Sealed Lead Acid (VRLA)
Battery recharge time 1.50 h
Design
International Protection (IP) code IP20
Form factor Compact
LED indicators Yes
Product colour Black
Certification CSA, FCC, NOM, UL
Display type LCD
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 45 °C
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Operating altitude 0 - 118110.2" (0 - 3000 m)
Non-operating altitude 0 - 590551.2" (0 - 15000 m)
Technical details
Output frequency 50/60 Hz
Sustainability certificates RoHS, ENERGY STAR
Weight & dimensions
Package width 24" (610 mm)
Package depth 37.8" (960 mm)
Package height 14.6" (370 mm)
Weight 134.9 lbs (61.2 kg)
Width 6.85" (174 mm)
Package weight 142 lbs (64.4 kg)
Height 17" (432 mm)
Depth 28.3" (719 mm)
Packaging data
Package width 24" (610 mm)
Package depth 37.8" (960 mm)
Package height 14.6" (370 mm)
Package weight 142 lbs (64.4 kg)
Logistics data
Products per pallet 6 pc(s)
Certificates
Certification CSA, FCC, NOM, UL
View full details
