Description
Breakthrough performance The Intel Solid-State Drive Data Center Family for PCIe brings extreme data throughput directly to Intel Xeon processors with up to six times faster data transfer speed than 6 Gbps SAS/SATA SSDs. The performance of a single drive from the Intel SSD Data Center Family for PCIe, specifically the Intel Solid-State Drive Data Center P3700 Series (460K IOPS), can replace the performance of 7 SATA SSDs aggregated through a host bus adapter (HBA) (approximately 500K IOPS). Modernizes data center storage Intel led the industry in creation of a new Non-Volatile Memory Express (NVMe) storage interface standard. NVMe overcomes SAS/SATA SSD performance limitations by optimizing hardware and software to take full advantage of NVM SSD technology. Comprehensive solution Intel is driving transition to NVMe SSDs by providing a comprehensive product line, enabling extensive system compatibility, delivering Intel drivers as well as supporting industry driver development, and completing numerous industry standard compliance certifications. Proven quality and reliability Intel SSD Data Center Family for PCIe devices are based on Intel-developed controller, firmware, and leading manufacturing process NAND flash memory. Rigorous qualification and compatibility testing ensures a highly reliable SSD. The Intel SSD Data Center Tool provides a powerful set of management capabilities.
Specification:
Hard drive | |
---|---|
PCI Express interface data lanes | x4 |
SSD capacity | 58 GB |
Memory type | 3D XPoint |
Performance | |
Intel High Endurance Technology (HET) | Yes |
Interface | PCI Express 3.0 |
Component for | Server/workstation |
NVMe | Yes |
TBW rating | 635 |
End-to-End Data Protection | Yes |
PCI Express interface data lanes | x4 |
SSD capacity | 58 GB |
Read speed | 1870 MB/s |
Write speed | 890 MB/s |
Memory type | 3D XPoint |
Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
Random write (4KB) | 224000 IOPS |
Random read (4KB) | 426000 IOPS |
SSD temperature monitoring | Yes |
Random write (100% span) | 224000 IOPS |
Random read (100% span) | 426000 IOPS |
Mean time between failures (MTBF) | 2000000 h |
Write latency | 10 µs |
Read latency | 7 µs |
Enhanced Power Loss Data Protection technology | Yes |
Data transmission | |
Read speed | 1870 MB/s |
Write speed | 890 MB/s |
Random write (4KB) | 224000 IOPS |
Random read (4KB) | 426000 IOPS |
Random write (100% span) | 224000 IOPS |
Random read (100% span) | 426000 IOPS |
Write latency | 10 µs |
Read latency | 7 µs |
Endurance | |
Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
Mean time between failures (MTBF) | 2000000 h |
Design | |
Component for | Server/workstation |
SSD form factor | M.2 |
Features | |
Interface | PCI Express 3.0 |
Component for | Server/workstation |
NVMe | Yes |
TBW rating | 635 |
End-to-End Data Protection | Yes |
PCI Express interface data lanes | x4 |
SSD capacity | 58 GB |
Read speed | 1870 MB/s |
Write speed | 890 MB/s |
Memory type | 3D XPoint |
Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
Random write (4KB) | 224000 IOPS |
Random read (4KB) | 426000 IOPS |
SSD temperature monitoring | Yes |
Random write (100% span) | 224000 IOPS |
Random read (100% span) | 426000 IOPS |
Mean time between failures (MTBF) | 2000000 h |
Write latency | 10 µs |
Read latency | 7 µs |
Enhanced Power Loss Data Protection technology | Yes |
SSD form factor | M.2 |
Harmonized System (HS) code | 84717070 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Use conditions | Communications Commercial Temp, Embedded Broad Market Commercial Temp, Industrial Commercial Temp, PC/Client/Tablet, Server/Enterprise, Workstation |
Power | |
Power consumption (write) | 4.1 W |
Power consumption (read) | 4.1 W |
Power consumption (idle) | 1.6 W |
Brand-specific features | |
Intel High Endurance Technology (HET) | Yes |
Operational conditions | |
Operating temperature (T-T) | 0 - 70 °C |
Operating shock | 1500 G |
Non-operating shock | 1500 G |
Operating vibration | 2.17 G |
Non-operating vibration | 3.13 G |
Maximum operating temperature | 70 °C |
Technical details | |
Interface | PCI Express 3.0 |
Operating temperature (T-T) | 0 - 70 °C |
Operating shock | 1500 G |
Non-operating shock | 1500 G |
Operating vibration | 2.17 G |
Non-operating vibration | 3.13 G |
SSD temperature monitoring | Yes |
Internal memory type | PCIe 3.0 x4, NVMe |
Intel High Endurance Technology (HET) | Yes |
Enhanced Power Loss Data Protection technology | Yes |
Power consumption (active) | 4.1 W |
SSD form factor | M.2 |
Processor family | Intel Optane DC SSD |
Status | Launched |
SSD shock | 1500G,0.5ms |
SSD endurance rating | 635 TBW |
Sequential writing speed | 890 MB/s |
Sequential reading | 1870 MB/s |
Launch date | Q2'21 |
Weight & dimensions | |
Width | 3.15" (80 mm) |
Height | 0.866" (22 mm) |
Other features | |
Processor family | Intel Optane DC SSD |
Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
Internal memory type | PCIe 3.0 x4, NVMe |
Power consumption (active) | 4.1 W |
Status | Launched |
SSD shock | 1500G,0.5ms |
SSD endurance rating | 635 TBW |
Sequential writing speed | 890 MB/s |
Sequential reading | 1870 MB/s |
Launch date | Q2'21 |
Target market | Gaming, Cloud Computing, High Performance Computing, Content Creation |
