SUINT1000LCD2U - Tripp Lite SMARTONLINE 208/230V 1KVA 900W DOUBLE-CONVERSION UPS, 2U, EXTENDED RUN, SNMP CAR

Double-Conversion UPS Protects Equipment against Damage, Downtime and Data Loss This 200/208/220/230/240V 50/60 Hz UPS system maintains perfect output by converting AC input to DC, then reconverting UPS output to fully regulated sine wave AC with +/-2% voltage regulation in online and battery modes. Featuring a 900W capacity, high 0.9 power factor, 627 joules of surge suppression, true on-line operation with pure sine wave output and zero transfer time to battery mode in on-line double-conversion mode, the SmartOnline SUINT1000LCD2U double-conversion UPS provides the highest level of AC power protection and battery backup for critical network closet, computer room and data center equipment. Set Power Strategies to Reflect Your Protection Priorities Pick your power strategy, from precise power for sensitive systems to the highest possible electrical efficiency, while ensuring 100% uptime. Choose from five selectable strategies: Max Efficiency, Max Quality, Frequency Regulation, Frequency Conversion and Auto Adaptive, which automatically offers increased efficiency when power conditions are good and enhanced power quality when power conditions are poor. Individually Controllable Load Banks Let You Access and Control Outlets Remotely Four C13 outlets are split evenly into two switchable load banks, allowing you to reboot select components or shed loads remotely. In addition to those four outlets, this UPS provides two more C13 outlets in their own unswitched bank for powering critical components. Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages The field-replaceable, hot-swappable internal battery (RBC24S) provides 12.3 minutes of support at half load (450W) and 4.7 minutes at full load (900W), keeping protected equipment operational through power failures. For mission-critical applications demanding scalable extended runtime, the UPS supports €œsmart€� external battery packs, such as Tripp Lite€™s BP24V36-2US (sold separately). Both the internal and external batteries are automatically sensed and configured during replacement to offer accurate runtime-remaining and battery age notifications. The intelligent battery management system with temperature-compensated charging extends battery life. Automatic Bypass Maintains Utility Output During Fault Conditions Auto-bypass mode keeps connected equipment powered and operational, even during UPS fault conditions. ENERGY STAR-Certified Economy Mode Helps You Save Money and Protect the Environment By meeting strict EPA efficiency guidelines, this ENERGY STAR-certified UPS system helps you save money and energy. A power-saving Economy mode setting option offers enhanced efficiency and reduced BTU output when utility power is already high quality. Automatically Turns Back On After Power Is Restored Battery-independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when batteries are expired and require replacement. Intuitive Front-Panel Interface for Convenient UPS Operation and Monitoring The front-panel LCD screen reports UPS operating mode, detailed UPS status and site-power information, as well as a variety of advanced UPS setup and configuration options. LEDs indicate AC input/output, battery and fault status. Advanced Communications Ports Allow for Automatic Saves and Shutdowns RS-232 and HID-compliant USB ports connect to a computer running Tripp Lite€™s free downloadable PowerAlert software to enable safe unattended file saves and system shutdown in case of a prolonged power failure. An EPO port connects the UPS to a contact closure switch to enable emergency inverter shutdown. Cables are included. Optional WEBCARDLX Network Interface Offers 24/7 Remote Access for Monitoring and Control The optional WEBCARDLX (sold separately) with the latest version of PowerAlert Device Manager firmware (PADM20) provides enhanced remote management capabilities, including customizable dashboard graphs to fit user preferences. The PADM20 upgrade and Tripp Lite€™s PowerAlert Element Manager (PAEM) software form a powerful tool for expanding maintenance functions in large installations, including firmware update checks and backup and restoration of device configurations. Auto Probe allows a UPS with switched loads to automatically reboot devices if a network communication failure is detected. Versatile Installation Options Hardware is included for mounting the UPS system in 2U of space in an EIA-standard 19-inch 4-post rack. Use the optional 2POSTRMKITWM (sold separately) for 2-post rack mounting or the optional 2-9USTAND (sold separately) for mounting in an upright tower position. The C14 power inlet accepts a variety of user-supplied input cords.



Specification:



Power
Output frequency	50/60 Hz
Output voltage regulation	2%
Output power	900 W
Input operation voltage (min)	200 V
Input operation voltage (max)	240 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	627 J
Emergency Power Off (EPO)	Yes
Power factor	0.9
Crest factor	3:1
Output power capacity	1 kVA
Input frequency	50/60 Hz
Performance
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Double-conversion (Online)
Waveform	Pure sine
Number of input phases	1
LED indicators	Yes
EMI/RFI noise filtering	Yes
Surge protection features	Digital Subscriber Line (DSL), Network
Noise level	45 dB
Audible alarm(s)	Yes
Features
Output frequency	50/60 Hz
Country of origin	China
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Double-conversion (Online)
Waveform	Pure sine
Output voltage regulation	2%
Number of input phases	1
Output power	900 W
Input operation voltage (min)	200 V
Input operation voltage (max)	240 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	627 J
EMI/RFI noise filtering	Yes
Surge protection features	Digital Subscriber Line (DSL), Network
Emergency Power Off (EPO)	Yes
Power factor	0.9
Noise level	45 dB
Crest factor	3:1
Audible alarm(s)	Yes
Output power capacity	1 kVA
Input frequency	50/60 Hz
Ports & interfaces
Emergency Power Off (EPO) connector	Yes
USB port	Yes
AC outlets quantity	6 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
USB 2.0 ports quantity	3
RS-232 ports	1
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	3
Battery
Typical backup time at half load	12.3 min
Typical backup time at full load	4.7 min
Hot-swap battery	Yes
Cold start	Yes
Design
Country of origin	China
Rack capacity	2U
Form factor	Rackmount/Tower
LED indicators	Yes
Product colour	Black
Cooling type	Active
Certification	CE, CSA (Canada), EAC (Belarus, Kazakhstan, Russia), SASO (Saudi Arabia), UL1778 (USA)
Built-in fan	Yes
Housing material	Metal
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	0 - 95%
Technical details
Output frequency	50/60 Hz
Sustainability certificates	RoHS, ENERGY STAR
Cooling
Cooling type	Active
Built-in fan	Yes
Weight & dimensions
Package width	19.8" (502.9 mm)
Package depth	23.5" (596.9 mm)
Package height	9.6" (243.8 mm)
Weight	28 lbs (12.7 kg)
Width	17.3" (438.2 mm)
Package weight	44.1 lbs (20 kg)
Height	3.5" (88.9 mm)
Depth	15.6" (397 mm)
Packaging data
Rack mount kit	Yes
Manual	Yes
Cables included	Output power cable, RS-232, USB cable
Package width	19.8" (502.9 mm)
Package depth	23.5" (596.9 mm)
Package height	9.6" (243.8 mm)
Package weight	44.1 lbs (20 kg)
Logistics data
Products per master (outer) case	1 pc(s)
Certificates
Certification	CE, CSA (Canada), EAC (Belarus, Kazakhstan, Russia), SASO (Saudi Arabia), UL1778 (USA)
Packaging content
Rack mount kit	Yes
Manual	Yes
Cables included	Output power cable, RS-232, USB cable
