SUINT1000XLCD - Tripp Lite 1000VA 900W INT SMART ONLINE UPS 230V DOUBLE-CONVERSION TOWER EXTENDED RUN NETWO

The SUINT1000XLCD SmartOnline 230V 1kVA 900W On-Line Double-Conversion UPS provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. It converts AC input to DC power, and then converts DC to fully regulated sine wave AC output with +/-2% voltage regulation in online, double-conversion mode. Featuring four C13 outlets, the SUINT1000XLCD has an internal battery that provides 12.8 minutes of support at half load (450W) and 4.8 minutes at full load (900W). Adding external battery packs, such as BP24V15RT-2U (sold separately), provides extended runtime. Operating in optional economy mode reduces heat output and cooling requirements and consumes less electricity. An interactive front-panel LCD screen displays operating conditions and diagnostic data, such as load, voltage and battery levels. An audible alarm signals UPS startup, power failure, low battery, overload, UPS fault and remote shutdown conditions. EMI/RFI line noise filtering improves your equipment€™s performance, and surge suppression prevents equipment and data damage from harmful power surges. With Tripp Lite€™s PowerAlert software, available via free download, SUINT1000XLCD enables safe unattended system shutdown and file saves in case of a prolonged power failure. A built-in card slot supports TLNETCARD, WEBCARDLX, SNMPWEBCARD, MODBUSCARD and RELAYIOCARD for network interface and remote monitoring and control. Protects Mission-Critical Rack-Mounted Equipment Provides fully regulated sine wave AC output for small/medium servers, networking equipment and telecom systems +/-2% voltage regulation in online, double-conversion mode 230V output voltage High 0.9 power factor offers 1000VA/900W output capacity 4 C13 outlets Set of 2 C13/C14 jumpers included Reliable Battery Backup with Expandable Runtime Supports half load for 12.8 min. and full load for 4.8 min. Zero transfer time suitable for advanced network applications Expandable runtime with optional external battery packs, such as Tripp Lite€™s BP24V15RT-2U Restarts automatically after lengthy power outages SNMP/Web Capability Built-in slot for SNMP network interface and relay card for remote monitoring and control options Compatible with TLNETCARD, WEBCARDLX, SNMPWEBCARD, MODBUSCARD and RELAYIOCARD Optional WEBCARDLX (sold separately) with the latest version of PowerAlert Device Manager firmware (PADM20) provides enhanced remote management capabilities PADM20 and PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large installations, including firmware update checks and backup and restoration of device configurations EMI/RFI Line Noise Filtering Removes electromagnetic and radio frequency interference that can disrupt or damage equipment€™s performance Interactive LCD Screen Reports detailed status information, including load, voltage and battery levels Audible Alarm Indicates startup/shutdown, power failure, low battery, overload and fault conditions Communications Ports USB & Serial ports enable data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download fromTripp Lite website. Optional Economy Mode Efficiently minimizes heat output, reduces cooling requirements and consumes less electricity



Specification:



Power
Output power	1350 W
Input operation voltage (min)	200 V
Input operation voltage (max)	240 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	936 J
Maximum current	7.49 A
Efficiency	93%
Emergency Power Off (EPO)	Yes
Power factor	0.9
Crest factor	3:1
Output power capacity	1.5 kVA
Input frequency	50/60 Hz
Performance
UPS topology	Double-conversion (Online)
Auto-restart	Yes
Automatic Voltage Regulation (AVR)	Yes
Number of input phases	1
LED indicators	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Power protection features	Over voltage, Under voltage
Noise level	45 dB
Audible alarm(s)	Yes
Features
Country of origin	China
UPS topology	Double-conversion (Online)
Auto-restart	Yes
Automatic Voltage Regulation (AVR)	Yes
Number of input phases	1
Output power	1350 W
Input operation voltage (min)	200 V
Input operation voltage (max)	240 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Surge energy rating	936 J
Maximum current	7.49 A
Efficiency	93%
EMI/RFI noise filtering	Yes
Surge protection	Yes
Emergency Power Off (EPO)	Yes
Power protection features	Over voltage, Under voltage
Power factor	0.9
Noise level	45 dB
Crest factor	3:1
Audible alarm(s)	Yes
Output power capacity	1.5 kVA
Input frequency	50/60 Hz
Ports & interfaces
AC outlets quantity	6 AC outlet(s)
AC outlet types	C13 coupler
Power plug	C14 coupler
USB 2.0 ports quantity	1
Serial ports quantity	1
Battery
Battery recharge time	5.8 h
Typical backup time at half load	12.6 min
Typical backup time at full load	4.5 min
Hot-swap battery	Yes
Cold start	Yes
Design
Country of origin	China
Rack capacity	2U
Form factor	Rackmount
LED indicators	Yes
Product colour	Black
Cooling type	Active
Certification	CE; ENERGY STAR Qualified; Tested to CSA (Canada); Tested to EAC (Belarus, Kazakhstan, Russia); Tested to SASO (Saudi Arabia); Tested to UL1778 (USA)
Housing material	Metal
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	5 - 95%
Technical details
Sustainability certificates	RoHS, ENERGY STAR
Cooling
Cooling type	Active
Weight & dimensions
Package width	22.2" (564.9 mm)
Package depth	27.6" (700 mm)
Package height	9.45" (240 mm)
Weight	45 lbs (20.4 kg)
Width	17.2" (437.9 mm)
Package weight	58 lbs (26.3 kg)
Height	3.46" (87.9 mm)
Depth	19.5" (496.1 mm)
Packaging data
Screws included	Yes
Rack mount kit	Yes
Manual	Yes
Cables included	Input power cable, Output power cable, Serial, USB cable
Package width	22.2" (564.9 mm)
Package depth	27.6" (700 mm)
Package height	9.45" (240 mm)
Package weight	58 lbs (26.3 kg)
Logistics data
Products per master (outer) case	1 pc(s)
Master (outer) case width	22.2" (564.9 mm)
Master (outer) case length	27.6" (700 mm)
Master (outer) case height	9.45" (240 mm)
Master (outer) case gross weight	58 lbs (26.3 kg)
Certificates
Certification	CE; ENERGY STAR Qualified; Tested to CSA (Canada); Tested to EAC (Belarus, Kazakhstan, Russia); Tested to SASO (Saudi Arabia); Tested to UL1778 (USA)
Packaging content
Screws included	Yes
Rack mount kit	Yes
Manual	Yes
Cables included	Input power cable, Output power cable, Serial, USB cable
