AT-2711FX/ST-901 - Allied Telesis AT 2711FX/ST - NETWORK ADAPTER - PLUG-IN CARD - PCI EXPRESS X1 - FAST ETHERNET

More Bandwidth with PCI-Express Interface AT-2711FX x1 PCI-Express (PCI-e ) design gives you the maxim possible bandwidth and bus efficiency, other benefits are: capability and Low Power Consumption. Easy Migration Path for AT-2701FX Users For the current customers who are using Allied Telesis€™ 100Mbps Fiber cards (AT-2701FX), and want to upgrade their systems to PCI-Express, AT-2711FX is the ultimate solution.The customers can continue using their existing 100Mbps Fiber network without adding any more new equipment. For new customers equipped with PCI-Express systems,AT-2711FX gives them the ability to easily build or connect to the Fast Ethernet Fiber networks. Advanced Manageability The priority queuing offered by AT-2711FX can help users set up the network based on their own needs.The comprehensive diagnostics and configuration software suite provides system administrators and engineers with a profound tool to analyze the network adapter and check specific data. High Reliability The AT-2711FX Fast Ethernet Fiber Adapter comes with a comprehesive Windows utility that performs detailed tests, diagnostics, and analysis.



Specification:



Ports & interfaces
Internal	Yes
Fiber optic connector	MT,SC
Interface	Ethernet
Host interface	PCI Express
Connectivity technology	Wired
Bandwidth
Full duplex	Yes
Maximum data transfer rate	100 Mbit/s
Wireless LAN features
Wi-Fi	Yes
Software
Windows operating systems supported	Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Linux operating systems supported	Yes
Indication
LED indicators	Yes
Network
Wi-Fi	Yes
Ethernet LAN	Yes
Networking standards	IEEE 802.3u,IEEE 802.3x
Full duplex	Yes
Fiber ethernet cabling technology	100BASE-FX
Maximum data transfer rate	100 Mbit/s
Performance
Windows operating systems supported	Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Linux operating systems supported	Yes
Design
Certification	FCC class A, EN55022 class A, VCCI class A, C-Tick, CE
Internal	Yes
LED indicators	Yes
Power
Power consumption	760 mA
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Operating altitude	0 - 120000" (0 - 3048 m)
Technical details
Sustainability certificates	RoHS
System requirements
Windows operating systems supported	Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Linux operating systems supported	Yes
Weight & dimensions
Width	4.21" (107 mm)
Height	2.2" (56 mm)
Weight	1.41 oz (40 g)
Certificates
Certification	FCC class A, EN55022 class A, VCCI class A, C-Tick, CE
