Description
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system. TPM (Trusted Platform Module) is a component that provides hardware level security upon system boot-up via stored security keys, passwords, encryption and hash functions. Internal IO expansion module indicates a mezzanine connector on Intel® Server Boards that supports a variety of Intel(r) I/O Expansion Modules using a x8 PCI Express* interface. These modules are either RoC (RAID-on-Chip) or SAS (Serial Attached SCSI) modules that are not used for external connectivity through the rear I/O panel.
Specification:
| Technical details | |
|---|---|
| Discrete graphics card model | Supported |
| Motherboard chipset | Intel® C226 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 1.2 |
| On-board graphics card | Yes |
| Number of processors supported | 1 |
| Number of DIMM slots | 4 |
| Intel® Virtualization Technology (Intel® VT) | VT-d |
| Intel Trusted Execution Technology | Yes |
| Intel Rapid Storage Technology | No |
| Intel Quiet System Technology (QST) | No |
| Intel Quick Resume Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel I/O Acceleration Technology | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | No |
| Intel Flex Memory Access | No |
| Intel Fast Memory Access | Yes |
| Intel Dual Display Capable Technology | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Motherboard form factor | micro ATX |
| Component for | Server |
| Graphics output | VGA |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 4 |
| Thermal Design Power (TDP) | 95 W |
| Product type | Server/Workstation Board |
| Maximum number of PCI Express lanes | 16 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| ECC supported by processor | Yes |
| Total number of SATA connectors | 6 |
| Intel Rapid Storage Technology enterprise | Yes |
| Maximum internal memory supported by processor | 32 GB |
| Status | Discontinued |
| Market segment | Server |
| Launch date | Q2'13 |
| FireWire support | No |
| Supported RAID configuration | Software RAID RST (0,1,10,5) and ESRT2 (0,1,10) |
| Maximum memory | 32 GB |
| Last change | 63903513 |
| Form factor | uATX |
| Last receipt attributes date | Thursday, August 31, 2017 |
| Last order date | Sunday, April 30, 2017 |
| End of life date announce | Sunday, October 30, 2016 |
| Additional information URL | http://www.intel.com/content/www/us/en/motherboards/server-motherboards/server-board-s1200v3rp.html |
| Performance | |
| Motherboard ARK ID | 71384 |
| Motherboard chipset | Intel® C226 |
| RAID levels | 0, 1, 5, 10 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 1.2 |
| Intel® Virtualization Technology (Intel® VT) | VT-d |
| Intel Trusted Execution Technology | Yes |
| Intel Rapid Storage Technology | No |
| Intel Quiet System Technology (QST) | No |
| Intel Quick Resume Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel I/O Acceleration Technology | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | No |
| Intel Flex Memory Access | No |
| Intel Fast Memory Access | Yes |
| Intel Dual Display Capable Technology | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Motherboard form factor | micro ATX |
| Component for | Server |
| Processor | |
| Processor manufacturer | Intel |
| Thermal Design Power (TDP) | 95 W |
| Maximum number of PCI Express lanes | 16 |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| ECC supported by processor | Yes |
| Maximum internal memory supported by processor | 32 GB |
| Compatible processor series | Intel® Xeon® E3 Family |
| Intel Xeon series | E3-1200 |
| Processor socket | LGA 1150 (Socket H3) |
| Product family | Single-socket server board |
| Product series | Intel S1200RP |
| Product codename | Rainbow Pass |
| Number of QPI links | 1 |
| Memory | |
| Supported memory types | DDR3L-SDRAM |
| Memory channels | Dual-channel |
| ECC | Yes |
| Supported memory clock speeds | 1333,1600 MHz |
| Supported UDIMM clock speeds | 1333,1600 MHz |
| Maximum internal memory | 32 GB |
| Maximum UDIMM memory | 32 GB |
| Unbuffered memory | Yes |
| Storage controllers | |
| Supported storage drive interfaces | SATA |
| RAID levels | 0, 1, 5, 10 |
| Graphics | |
| On-board graphics card | Yes |
| Internal I/O | |
| Total number of SATA connectors | 6 |
| Supported storage drive interfaces | SATA |
| Number of SATA connectors | 6 |
| Rear panel I/O ports | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | Gigabit Ethernet |
| Features | |
| Motherboard ARK ID | 71384 |
| Motherboard chipset | Intel® C226 |
| Motherboard form factor | micro ATX |
| Component for | Server |
| Market segment | Server |
| Harmonized System (HS) code | 8473301180 |
| Commodity Classification Automated Tracking System (CCATS) | G145323 |
| Export Control Classification Number (ECCN) | 5A992C |
| Rack-Friendly board | Yes |
| Physical Address Extension (PAE) | 40 bit |
| Embedded USB (eUSB) SSD option | Yes |
| Expansion slots | |
| PCI Express x1 (Gen 2.x) slots | 1 |
| PCI Express x4 (Gen 2.x) slots | 1 |
| PCI Express x8 (Gen 2.x) slots | 1 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| PCI Express slots version | 3.0 |
| PCI Express CEM revision | 3.0 |
| Processor special features | |
| Intel Clear Video Technology | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Rapid Storage Technology enterprise | Yes |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 1.2 |
| Intel® Virtualization Technology (Intel® VT) | VT-d |
| Intel Trusted Execution Technology | Yes |
| Intel Rapid Storage Technology | No |
| Intel Quiet System Technology (QST) | No |
| Intel Quick Resume Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel I/O Acceleration Technology | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | No |
| Intel Flex Memory Access | No |
| Intel Fast Memory Access | Yes |
| Intel Dual Display Capable Technology | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Intel Server Management Software | Yes |
| Intel Server Customization Technology | No |
| Intel Remote Management Module Support | Yes |
| Intel Quiet Thermal Technology | No |
| Intel Intelligent Power Node Manager | Yes |
| Intel Efficient Power Technology | No |
| Intel Build Assurance Technology | No |
| Intel Advanced Management Technology | Yes |
| Integrated BMC with IPMI | Yes |
| Connector for Intel I/O Expansion Module x8 Gen 3 | 1 |
| Integrated systems available | Yes |
| Design | |
| Product family | Single-socket server board |
| Product series | Intel S1200RP |
| Product codename | Rainbow Pass |
| Weight & dimensions | |
| Width | 9.61" (244 mm) |
| Depth | 9.61" (244 mm) |
| Packaging content | |
| Cables included | SATA |
| Other features | |
| Thermal Design Power (TDP) | 95 W |
| Motherboard ARK ID | 71384 |
| PCI Express x8 (Gen 2.x) slots | 1 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| Discrete graphics card model | Supported |
| Supported UDIMM clock speeds | 1333,1600 MHz |
| Maximum UDIMM memory | 32 GB |
| Number of processors supported | 1 |
| Number of DIMM slots | 4 |
| Intel Xeon series | E3-1200 |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Graphics output | VGA |
| Commodity Classification Automated Tracking System (CCATS) | G145323 |
| Export Control Classification Number (ECCN) | 5A992C |
| PCI Express CEM revision | 3.0 |
| Packaging content | Intel Server Board S1200V3RPL with (4) SATA Cables (1) I/O Shield (1) Intel Server Deployment & Management DVD (1) Attention document and (1) Quick Start User’s Guide. Note: the OEM 10 Pack does not ship with included items. |
| Chassis type | Rack (4) |
| Intel Node Manager | Yes |
