| Design | |
|---|---|
| Product type | Mobile workstation |
| Market positioning | High performance |
| Housing material | Glass fiber, Plastic |
| Form factor | Clamshell |
| Product colour | Black |
| Display | |
| HD type | Full HD |
| LED backlight | Yes |
| Display brightness | 250 cd/m² |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 15.6" |
| Screen shape | Flat |
| Native aspect ratio | 16:9 |
| Processor | |
| Stepping | H0 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Kaby Lake |
| Bus type | OPI |
| Tjunction | 100 °C |
| Thermal Design Power (TDP) | 15 W |
| Processor series | Intel Core i5-7300 Mobile Series |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x2+2x1,1x4,2x2,4x1 |
| Maximum number of PCI Express lanes | 12 |
| Configurable TDP-down | 7.5 W |
| ECC supported by processor | No |
| Configurable TDP-down frequency | 0.8 GHz |
| Processor cache type | Smart Cache |
| Conflict-Free processor | Yes |
| Processor cache | 3 MB |
| Processor frequency | 2.6 GHz |
| Processor model | i5-7300U |
| Processor boost frequency | 3.5 GHz |
| Processor cores | 2 |
| Processor threads | 4 |
| System bus rate | 4 GT/s |
| Processor socket | BGA 1356 |
| Processor manufacturer | Intel |
| Processor family | 7th gen Intel® Core™ i5 |
| Configurable TDP-up frequency | 2.7 GHz |
| Configurable TDP-up | 25 W |
| Memory | |
| Memory form factor | SO-DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2133 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Maximum internal memory (64-bit) | 32 GB |
| Storage | |
| Storage media | HDD |
| Optical drive type | No |
| Card reader integrated | Yes |
| Compatible memory cards | MMC,SD,SDHC,SDXC |
| Graphics | |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| On-board graphics adapter base frequency | 300 MHz |
| Maximum on-board graphics adapter memory | 32 GB |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter ID | 0x5916 |
| On-board graphics adapter family | Intel® HD Graphics |
| On-board graphics adapter | Yes |
| On-board graphics adapter model | Intel® HD Graphics 620 |
| Discrete graphics adapter model | NVIDIA® Quadro® M520 |
| Audio | |
| Audio chip | Realtek ALC3268 |
| Number of built-in speakers | 2 |
| Speaker power | 2 W |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Optical drive | |
| Optical drive type | No |
| LightScribe | No |
| Network | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Sleep-and-Charge ports | 1 |
| USB Sleep-and-Charge | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4b |
| DVI port | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Docking connector | Yes |
| Mini DisplayPorts quantity | 1 |
| Charging port type | DC-in jack |
| Keyboard | |
| Pointing device | ThinkPad UltraNav |
| Numeric keypad | Yes |
| Windows keys | Yes |
| Spill-resistant keyboard | Yes |
| Keyboard backlit | Yes |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Technical details | |
| Power cord included | Yes |
| Market positioning | High performance |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Smart Response Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Housing material | Glass fiber, Plastic |
| Form factor | Clamshell |
| Product colour | Black |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Sustainability certificates | RoHS, EPEAT Gold, ENERGY STAR |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel® Secure Key | Yes |
| Intel Flex Memory Access | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Thermal Monitoring Technologies | Yes |
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
| Processor package size | 42 X 24 mm |
| Processor code | SR340 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Intel Stable Image Platform Program (SIPP) version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Identity Protection Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Conflict-Free processor | Yes |
| Processor ARK ID | 97472 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Smart Response Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 3+4 |
| Battery life (max) | 13.8 h |
| Power | |
| AC adapter power | 65 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Password protection | Yes |
| Trusted Platform Module (TPM) | Yes |
| Password protection type | HDD, Power on, Supervisor |
| Cable lock slot | Yes |
| Sustainability | |
| Sustainability certificates | RoHS, EPEAT Gold, ENERGY STAR |
| Weight & dimensions | |
| Width | 14.4" (365.8 mm) |
| Depth | 9.95" (252.8 mm) |
| Height (front) | 0.787" (2 cm) |
| Height (rear) | 0.795" (2.02 cm) |
| Weight | 4.39 lbs (1.99 kg) |
| Packaging data | |
| Power cord included | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Packaging content | |
| Power cord included | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Other features | |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| Maximum on-board graphics adapter memory | 32 GB |
| On-board graphics adapter | Yes |
| LightScribe | No |
| Maximum internal memory (64-bit) | 32 GB |
| AC adapter included | Yes |
