| Processor | |
|---|---|
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Thermal Design Power (TDP) | 125 W |
| Tcase | 78 °C |
| Supported instruction sets | AVX,AVX 2.0,AVX-512,SSE4.2 |
| Stepping | U0 |
| Scalability | 2S |
| Processor threads | 6 |
| Processor package size | 76.0 x 56.5 mm |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Skylake |
| Processor code | SR3GM |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2133 MHz |
| Maximum number of PCI Express lanes | 48 |
| Maximum internal memory supported by processor | 768 GB |
| Execute Disable Bit | Yes |
| Embedded options available | No |
| Processor cache type | L3 |
| Processor cache | 22 MB |
| Conflict-Free processor | Yes |
| Processor frequency | 2.3 GHz |
| Number of processors installed | 1 |
| Processor model | 5218 |
| Processor boost frequency | 3.9 GHz |
| Processor socket | LGA 3647 (Socket P) |
| Processor cores | 16 |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® Gold |
| Memory | |
| Internal memory | 32 GB |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory slots | 12 |
| Memory clock speed | 2666 MHz |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Storage | |
| Supported RAID controllers | 930-16i |
| Hot-swap | Yes |
| RAID support | Yes |
| RAID levels | 0,1,5,6,10,50,60 |
| Optical drive type | No |
| HDD size | 2.5" |
| HDD interface | Serial ATA III, Serial Attached SCSI (SAS) |
| Graphics | |
| On-board graphics adapter model | Not available |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| VGA (D-Sub) ports quantity | 1 |
| USB 2.0 ports quantity | 5 |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Optical drive | |
| Optical drive type | No |
| Design | |
| Rack mounting | Yes |
| Optical drive type | No |
| Chassis type | Tower (4U) |
| Product colour | Black |
| Performance | |
| Compatible operating systems | Microsoft Windows Server 2016/2012 R2. Red Hat Enterprise Linux 7.3/6.9. SUSE Linux Enterprise Server 12 SP2/11 SP4. VMware vSphere (ESXi) 6.5/6.0 U3 |
| Performance management | XClarity Controller |
| Trusted Platform Module (TPM) | Yes |
| Software | |
| Compatible operating systems | Microsoft Windows Server 2016/2012 R2. Red Hat Enterprise Linux 7.3/6.9. SUSE Linux Enterprise Server 12 SP2/11 SP4. VMware vSphere (ESXi) 6.5/6.0 U3 |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Turbo Boost Technology | No |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 1.00 |
| Processor ARK ID | 123546 |
| Power | |
| Number of main power supplies | 1 |
| Number of redundant power supplies supported | 2 |
| Redundant power supply (RPS) support | Yes |
| Power supply | 750 W |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating altitude | 0 - 120000" (0 - 3048 m) |
| Technical details | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Trusted Platform Module (TPM) | Yes |
| Rack mounting | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Chassis type | Tower (4U) |
| Sustainability certificates | ENERGY STAR |
| Management features | |
| Performance management | XClarity Controller |
| Weight & dimensions | |
| Width | 6.93" (176 mm) |
| Weight | 79.4 lbs (36 kg) |
| Height | 17.2" (438 mm) |
| Depth | 26.4" (670 mm) |
