Description
| Processor | |
|---|---|
| Processor generation | 12th gen Intel® Core™ i7 |
| Bus type | DMI4 |
| Processor cache | 25 MB |
| Processor model | i7-12700 |
| Processor manufacturer | Intel |
| Processor boost frequency | 4.9 GHz |
| Processor cores | 12 |
| Processor family | Intel® Core™ i7 |
| Memory | |
| Non-ECC | Yes |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Maximum internal memory | 128 GB |
| Memory slots | 4x DIMM |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory channels | Dual-channel |
| Storage | |
| Storage media | HDD+SSD |
| Number of storage drives installed | 2 |
| Number of HDDs installed | 1 |
| Optical drive type | No |
| HDD speed | 7200 RPM |
| SSD interface | NVMe, PCI Express 4.0 |
| Number of SSDs installed | 1 |
| HDD size | 3.5" |
| Card reader integrated | No |
| Total storage capacity | 1256 GB |
| SSD form factor | M.2 |
| Total HDDs capacity | 1000 GB |
| Total SSDs capacity | 256 GB |
| NVMe | Yes |
| Graphics | |
| Discrete graphics card | Yes |
| Graphics card HDMI ports quantity | 1 |
| Graphics card DisplayPorts quantity | 3 |
| Discrete graphics card memory | 12 GB |
| On-board graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 3060 |
| Discrete graphics memory type | GDDR6 |
| On-board graphics card model | Intel UHD Graphics 770 |
| Number of discrete graphics cards | 1 |
| Discrete GPU manufacturer | NVIDIA |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Technical details | |
| Intel 64 | Yes |
| Product type | PC |
| Trusted Platform Module (TPM) | Yes |
| Product colour | Black |
| Chassis type | Tower |
| Audio system | High Definition Audio |
| Motherboard chipset | Intel B660 |
| Design | |
| Volume | 26 L |
| Product colour | Black |
| Chassis type | Tower |
| Performance | |
| Embedded options available | No |
| Password protection | Yes |
| Password protection type | HDD, Power on, Supervisor |
| Product type | PC |
| Trusted Platform Module (TPM) | Yes |
| Audio system | High Definition Audio |
| Motherboard chipset | Intel B660 |
| Software | |
| Operating system language | English |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Home |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel 64 | Yes |
| Power | |
| Power supply input voltage | 100 - 240 V |
| Power supply | 500 W |
| Operational conditions | |
| Operating altitude | 0 - 120000" (0 - 3048 m) |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Non-operating altitude | 0 - 480000" (0 - 12192 m) |
| Certificates | |
| Certification | ENERGY STAR 8.0 ErP Lot 3 RoHS |
| Weight & dimensions | |
| Volume | 26 L |
| Package width | 14.6" (370 mm) |
| Package depth | 19.1" (485 mm) |
| Package height | 21.7" (550 mm) |
| Width | 8.07" (205 mm) |
| Depth | 15.6" (395.4 mm) |
| Height | 16.5" (420 mm) |
| Package weight | 35.3 lbs (16 kg) |
| Weight | 30.9 lbs (14 kg) |
| Packaging data | |
| Package width | 14.6" (370 mm) |
| Package depth | 19.1" (485 mm) |
| Package height | 21.7" (550 mm) |
| Package weight | 35.3 lbs (16 kg) |
| Packaging content | |
| Mouse included | Yes |
| Display included | No |
| Keyboard included | Yes |
| Other features | |
| Trusted Platform Module (TPM) | Yes |
| On-board graphics card | Yes |
| Processor manufacturer | Intel |
Specification:
| Hard drive | |
|---|---|
| RAID levels | 0,1,5,10 |
| Hot-swap HDD bays | Yes |
| Optical drive | |
| Optical drive type | DVD-RW |
| Software | |
| Compatible operating systems | Windows Server 2008 R2 *(Subject to change without any notice) Windows® Server 2012 R2 Windows® Server 2012 RedHat® Enterprise Linux SuSE® Linux Enterprise Server CentOS Ubuntu VMware Citrix XenServer |
| Processor | |
| Processor socket | LGA 2011-v3 |
| Number of processors supported | 2 |
| Motherboard chipset | Intel® C612 |
| Intel Xeon series | E5-2600 |
| Compatible processor series | Intel® Xeon® E5 Family |
| Processor manufacturer | Intel |
| Design | |
| 80 PLUS certification | 80 PLUS Platinum |
| Chassis type | Rack (1U) |
| Memory | |
| Supported RDIMM clock speeds | 1333,1600,1866,2133 MHz |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 4GB, 8GB, 16GB, 32GB, 64GB |
| Number of DIMM slots | 24 |
| Maximum internal memory | 1536 GB |
| Storage | |
| Number of storage drives supported | 4 |
| Number of 3.5" bays | 4 |
| RAID levels | 0,1,5,10 |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | 3.5" |
| Performance | |
| Optical drive type | DVD-RW |
| Compatible operating systems | Windows Server 2008 R2 *(Subject to change without any notice) Windows® Server 2012 R2 Windows® Server 2012 RedHat® Enterprise Linux SuSE® Linux Enterprise Server CentOS Ubuntu VMware Citrix XenServer |
| Graphics | |
| On-board graphics adapter model | Aspeed AST2400 |
| On-board graphics adapter memory | 32 MB |
| Network | |
| LAN controller | Intel® I350-AM2 |
| Ethernet LAN | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| Serial ports quantity | 1 |
| PS/2 ports quantity | 1 |
| IPMI LAN (RJ-45) port | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots | |
| PCI Express x8 slots | 2 |
| PCI Express x16 slots | 2 |
| Features | |
| Optical drive type | DVD-RW |
| Compatible operating systems | Windows Server 2008 R2 *(Subject to change without any notice) Windows® Server 2012 R2 Windows® Server 2012 RedHat® Enterprise Linux SuSE® Linux Enterprise Server CentOS Ubuntu VMware Citrix XenServer |
| Technical details | |
| Number of storage drives supported | 4 |
| Number of 3.5" bays | 4 |
| Chassis type | Rack (1U) |
| Power | |
| AC input frequency | 47 - 63 Hz |
| Number of redundant power supplies supported | 2 |
| Power supply | 800 W |
| 80 PLUS certification | 80 PLUS Platinum |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Weight & dimensions | |
| Width | 27" (686 mm) |
| Weight | 26.2 lbs (11.9 kg) |
| Height | 1.73" (44 mm) |
| Depth | 17.5" (444 mm) |
