Description
Intel® Virtualization Technology for Directed I/O (VT-d) Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments. Intel® Rapid Storage Technology Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology. Intel® Virtualization Technology (VT-x) Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual†platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions. Intel® Platform Trust Technology (Intel® PTT) Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
Specification:
| Motherboard | |
|---|---|
| Number of processors supported | 1 |
| Motherboard chipset | Intel Z690 |
| Processor | |
| Thermal Design Power (TDP) | 125 W |
| Built-in processor | Yes |
| Processor model | i7-13700K |
| Processor boost frequency | 5.4 GHz |
| Processor threads | 24 |
| Processor cores | 16 |
| Processor family | Intel® Core™ i7 |
| Number of processors supported | 1 |
| Motherboard chipset | Intel Z690 |
| L2 cache | 24 MB |
| Processor manufacturer | Intel |
| Processor cache | 30 MB |
| Processor generation | 13th gen Intel® Core™ i7 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Memory channels | Dual-channel |
| ECC | No |
| Supported memory types | DDR-SDRAM |
| Maximum internal memory | 64 GB |
| Number of DIMM slots | 2 |
| Video | |
| On-board graphics card | No |
| Graphics card family | Intel |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Storage drive sizes supported | M.2,2.5 |
| Storage drive interface | PCI Express, Serial ATA III |
| Number of storage drives supported | 5 |
| RAID levels | 0, 1 |
| SSD form factor | M.2 |
| Graphics | |
| Maximum resolution | 7680 x 4320 pixels |
| Number of displays supported | 3 |
| On-board graphics card | No |
| Graphics card family | Intel |
| On-board graphics card model | Intel UHD Graphics 770 |
| Audio | |
| Audio output channels | 7.1 channels |
| Built-in speaker(s) | No |
| Network | |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Killer Wi-Fi 6E AX1690 |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| M.2 card slot (wireless) | Killerâ„¢ Wi-Fi 6E AX1690i |
| USB ports quantity | 11 |
| M.2 card slot (storage) | 2 via PCH + 1 via CPU (NVMe) |
| Thunderbolt 4 ports quantity | 2 |
| Expansion slots | |
| PCI Express slots version | 5, 4.0 |
| Design | |
| Product type | PC barebone |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| ARK ID | 229784 |
| On/off switch | Yes |
| LED indicators | Yes |
| Cooling type | Active |
| Product colour | Black |
| Chassis type | Desktop |
| Certification | IEC/EN/UL 60950-1 IEC/EN/UL 62368-1 FCC Part 15B/15C/15E CISPR/EN 55032/55024 ICES-003 VCCI 32 BSMI CNS 13438 KN 32/35 AS/NZS CISPR 32 EN 300 328 EN 301 893 EN 300 440 EN 301 489-1/3/17 EN 62311 AS/NZS 4268 AS/NZS 2772.2 ARPANSA |
| Product family | Intel NUC |
| Product series | Intel NUC kit |
| Product codename | Raptor Canyon |
| Status | Launched |
| Performance | |
| Maximum resolution | 7680 x 4320 pixels |
| Windows operating systems supported | Windows 11 x64 |
| Linux operating systems supported | Yes |
| BIOS type | EEPROM |
| Number of displays supported | 3 |
| Operating system installed | No |
| Number of processors supported | 1 |
| Motherboard chipset | Intel Z690 |
| Compatible operating systems | Windows 11 (64-bit) |
| Audio output channels | 7.1 channels |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Harmonized System (HS) code | 8471500150 |
| Export Control Classification Number (ECCN) | 5A992C |
| Software | |
| Operating system installed | No |
| Compatible operating systems | Windows 11 (64-bit) |
| Processor special features | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel Rapid Storage Technology | Yes |
| Embedded options available | No |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Colour | |
| Product colour | Black |
| Technical details | |
| BIOS type | EEPROM |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Intel Rapid Storage Technology | Yes |
| Embedded options available | No |
| RAID levels | 0, 1 |
| Processor cores | 16 |
| Cooling type | Active |
| Chassis type | Desktop |
| Sustainability certificates | ENERGY STAR, RoHS |
| Introduction year | 2022 |
| Warranty period | 3 year(s) |
| ARK ID | 229784 |
| Internal I/O | |
| Number of SATA connectors | 4 |
| Indication | |
| LED indicators | Yes |
| Management features | |
| On/off switch | Yes |
| Features | |
| Number of displays supported | 3 |
| Logistics data | |
| Harmonized System (HS) code | 8471500150 |
| Power | |
| Power supply type | Internal power supply unit |
| Power supply | 750 W |
| Number of power supply units | 1 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 40 °C |
| Operating temperature (T-T) | 0 - 35 °C |
| Certificates | |
| Certification | IEC/EN/UL 60950-1 IEC/EN/UL 62368-1 FCC Part 15B/15C/15E CISPR/EN 55032/55024 ICES-003 VCCI 32 BSMI CNS 13438 KN 32/35 AS/NZS CISPR 32 EN 300 328 EN 301 893 EN 300 440 EN 301 489-1/3/17 EN 62311 AS/NZS 4268 AS/NZS 2772.2 ARPANSA |
| Weight & dimensions | |
| Width | 13.3" (337 mm) |
| Depth | 13.3" (337 mm) |
| Height | 12.5" (318 mm) |
| Other features | |
| Embedded options available | No |
| Number of SATA connectors | 4 |
| HDD size | 2.5" |
| Chassis type | Desktop |
| Additional headers | FRONT_PANEL |
| Launch date | Q4'22 |
